BOPP tape coating machine
Product purpose:
Suitable for BOPP tape coating process.
Suitable for BOPP tape coating process.
-
Product description:
1. The double station unwinding and winding unit can realize high-speed non-stop film change and connection, with intelligent operation and high yield;
2. It is recommended to select wire rod head to realize high-speed and precision coating. If it is within 200m / min, it can be selected as Teaser roller type;
3. The oven can be traditional or open box, with low-temperature drying, environmental protection and energy saving, accurate temperature control and flexible operation of guide roller;
4. The whole machine adopts sectional tension control to keep the materials running smoothly at high speed, without wrinkles and winding neatly.
Technical parameters：
Coating width (Customizable): 500~1800mm Base material： BOPP film ， thinckness 23~60μm Glue type： Water based acrylic adhesive，solid content 50~55%，Viscosity 100~3000cps Machine speed(Customizable): 50~350Meters per minute Coating amount： thickness 12~30μm after drying Accuracy of coating: ±0.0015mm Coating way: Mayer-bar, Comma roller Accuracy of tension control: ±0.15kg Edge uniformity of jumbo roll: ±3mm Unwinding roll diameter: Maximum 800mm Rewinding roll diameter: Maximum 800mm
